0.8-9t manual lever hoist/lever chain block, (LH-KV type)

H-Lift manual chain hoists are commonly known as chain blocks and are designed for heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.Characteristics of manual lev

Featured Products

H-Lift manual chain hoists are commonly known as chain blocks and are designed for heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.

Characteristics of manual lever hoist LH-KV Type

1. H-LIFT lever hoist is a universal, manual hoist for lifting, tensioning and lashing in any direction.

2. The ratchet lever hoist features compact design and robust, deep drawn, stamped steel construction.

3. High quality materials ensure lightweight without infringing reliability.

4. Low own weight, small mounting sizes and small lever force at full load.

5. Asbestos-free brake, holding load at any desired height.

6. Top & bottom hooks are fitted with safety latches as standard.

7. The load chain can be pulled freely and easily through the hoist in both directions to attach the load or to tension the chain. For safety reason, free chains can not be done when the hoist is under load.

8. Complies with EC Council Directive 2006/42/EC Machinery, ASME B30.16, AS 1418.2.


Specification:

0.8-9t Manual Lever Hoist/ Lever Chain Block, (LH-KV Type)
ModelLHKV080LHKV100LHKV160LHKV320LHKV630LHKV900
Capacityt0.811.63.26.39
Standard Liftm1.51.51.51.51.51.5
Proof LoadkN11.7614.7023.5247.0492.61132.30
Effort Required to Lift Rated LoadN215294304372382392
No. of Falls of Load Chain

111123
Load Chainmm5.6x15.75.6x15.77.1x19.910x2810x2810x28
Dimensions(mm)a146146164196196196
b119119126159218298
c41.549.45261.984.3-
d280300335395540680
e245245265415415415
f9696100114114114
g26.531.535.5435364
h35.542.542.5506085
Net Weightkg5.75.9813.62640


0.8-9t Manual Lever Hoist/ Lever Chain Block, (LH-KV Type)

Company information:

H-Lift, an ISO 9001 certified firm by Lloyd's Register and a member of LEEA(Lifting Equipment Engineers Association), specializes in the field of lifting & hoisting equipment, webbing and round sling, Ratchet Tie Down and lashing equipment, chain & chain sling, wire rope and wire rope sling, material handling, rigging hardware & other products.
