Lifting Crane Vital 1 ton Chain Block HSZ-VT Chain Hoist
Production specifications:
The HS Series VT Hand Chain Hoist features a simple, efficient and economical design. Its compact design, low headroom and lightweight steel construction makes this hoist easy to install and operate , even in confined spaces
HSVT Type Chain Hoist / JAPAN VITAL MODEL
Features:
1.Double pawls supporting fail-safe break mechanism for secure operations.
2.Wet friction discs with longer life.
3.Unique chain guide.
4.Heat treated steel side plates, gears and shafts for enhanced strength.
5.Quenched and Tempered High Tensile Alloy Steel Chain and hooks.
6.Forged upper and bottom hooks with forged steel safety latches.
7.Powder coated finish.
Specifications sheet as belows:
Factory Price Forged Chains 2 Ton Vital Chain Block Parameters | ||||||||||
| Model | HS-VT 0.5 | HS-VT 1 | HS-VT 1.5 | HS-VT 2 | HS-VT 3 | HS-VT 5 | HS-VT 10 | HS-VT 20 | HS-VT 30 | HS-VT 50 |
| Capacity(t) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 30 | 50 |
| Standard lift(m) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Running test load(t) | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 15 | 30 | 45 | 75 |
| No.of falls of load chain | 1 | 1 | 1 | 1 | 2 | 2 | 4 | 8 | 12 | 24 |
| Load chain diameter(mm) | 5 | 6.3 | 7.1 | 8 | 7.1 | 9 | 9 | 9 | 9 | 9 |
| Net weight(kg) | 8.4 | 12 | 16.2 | 20 | 24 | 41 | 79 | 193 | 220 | 1092 |
| Packing(L*W*H)(cm) | 22*14*15 | 25*19*16 | 33*24*16 | 33*24*19 | 34.5*24*16 | 40*30*19 | 48*42*18.5 | 78*68*20 | 85*67*30 | 110*100*130 |
